I made a dashboard with 6 major components. Two plots display data on the left, and incremental change on the right. A radio button groups the data by decade or year, with 2nd radio button for plotting with px.line or px.area. Group by decade has the sums for each year of that decade, with 2020s excluded for only having 2 years in data set.
The middle section has a px.scatter correlation graph on the left, and correlation statistics in dbc cards on the right. Radio buttons select the X axis and Y axis parameters. When same parameter is used on both axes, you can see best case, ideal correlation stats. A best fit line was added as a go.Scatter trace.
Bottom has a dash-ag table and a card describing each parameter. I renamed all columns and kept the original long descriptive text for the parameter descriptions on the right, and as dash-ag tooltips.
Here is the code:
import polars as pl
import plotly.express as px
import plotly.graph_objects as go
from dash import Dash, dcc, html, Input, Output
import dash_bootstrap_components as dbc
import dash_ag_grid as dag
import dash_mantine_components as dmc
import dash
from scipy import stats
dash._dash_renderer._set_react_version('18.2.0')
#----- GLOBALS -----------------------------------------------------------------
data_src ='Data Source: https://rieee.appstate.edu/projects-programs/cdiac/'
df_col_defs = [c for c in pl.scan_csv('global.1751_2021.csv').collect_schema()]
short_col_names = [
'YEAR', 'FOSSIL', 'SOLID', 'LIQUID', 'GAS',
'CEMENT', 'FLARING', 'PER_CAP','DECADE']
dict_cols = dict(zip(df_col_defs, short_col_names))
dict_cols_reversed = dict(zip(short_col_names, df_col_defs))
dag_columns = [
'DECADE', 'YEAR', 'CEMENT', 'FLARING', 'FOSSIL',
'GAS', 'LIQUID', 'SOLID', 'PER_CAP', ]
style_horiz_line = {'border': 'none', 'height': '4px',
'background': 'linear-gradient(to right, #007bff, #ff7b00)',
'margin': '10px,', 'fontsize': 32}
style_h2 = {'text-align': 'center', 'font-size': '32px'}
style_h3 = {
'text-align': 'center', 'font-size': '16px', 'font-weight': 'normal'}
#----- DASHBOARD COMPONENTS ----------------------------------------------------
grid = dag.AgGrid(
rowData=[],
columnDefs=[
{"field": i, 'filter': True, 'sortable': True,
'tooltipField': i, 'headerTooltip': dict_cols_reversed.get(i) }
for i in dag_columns
],
dashGridOptions={"pagination": True},
columnSize="responsiveSizeToFit",
id='dash_ag_table',
)
definition_card = dbc.Card([
dbc.CardBody([
dbc.ListGroup(
[
dbc.ListGroupItem(f'CEMENT: {dict_cols_reversed['CEMENT']}'),
dbc.ListGroupItem(f'FLARING: {dict_cols_reversed['FLARING']}'),
dbc.ListGroupItem(f'FOSSIL: {dict_cols_reversed['FOSSIL']}'),
dbc.ListGroupItem(f'GAS: {dict_cols_reversed['GAS']}'),
dbc.ListGroupItem(f'LIQUID: {dict_cols_reversed['LIQUID']}'),
dbc.ListGroupItem(f'SOLID: {dict_cols_reversed['SOLID']}'),
dbc.ListGroupItem(f'PER_CAP: {dict_cols_reversed['PER_CAP']}'),
],
)
]),
])
regression_stats_card = (
dbc.Card([
html.H3('Stats', className='card-header',),
dbc.ListGroup([
dbc.ListGroupItem('Slope'),
dbc.ListGroupItem('Slope', id='lg_slope_val'),
],
horizontal=True,
flush=True,
),
dbc.ListGroup([
dbc.ListGroupItem('Intercept'),
dbc.ListGroupItem('Intercept', id='lg_intcpt_val'),
],
horizontal=True,
flush=True,
),
dbc.ListGroup([
dbc.ListGroupItem('Correlation'),
dbc.ListGroupItem('Correlation', id='lg_corr_val'),
],
horizontal=True,
flush=True,
),
dbc.ListGroup([
dbc.ListGroupItem('Standard Error'),
dbc.ListGroupItem('Standard Error', id='lg_stderr'),
],
horizontal=True,
flush=True,
),
dbc.ListGroup([
dbc.ListGroupItem('Intercept Std Err'),
dbc.ListGroupItem('Intercept Std Err', id='lg_i_stderr'),
],
horizontal=True,
flush=True,
),
]),
)
#----- READ & CLEAN DATASET, STORE AS 4 DATAFRAMES -----------------------------
df_year = (
pl.scan_csv('global.1751_2021.csv') # lazyframe
.rename(dict_cols)
.with_columns(
pl.col('PER_CAP').cast(pl.Float32),
pl.col('YEAR').cast(pl.String)
)
.with_columns(
DECADE = pl.col('YEAR').str.slice(0,3) + pl.lit("0's")
)
.collect() # dataframe
)
df_year_diff = (
df_year
.lazy() # lazyframe
.with_columns(
pl.col(
'FOSSIL', 'SOLID', 'LIQUID', 'GAS',
'CEMENT', 'FLARING', 'PER_CAP'
).diff()
)
.collect() # dataframe
)
df_decade = (
df_year
.lazy() # lazyframe
.with_columns(DECADE = pl.col('YEAR').str.slice(0,3) + pl.lit("0's"))
.filter(pl.col('DECADE') != "2020's") # only data for 2 years in the 2020s
.group_by('DECADE').agg(
pl.col('FOSSIL').sum(),
pl.col('SOLID').sum(),
pl.col('LIQUID').sum(),
pl.col('GAS').sum(),
pl.col('CEMENT').sum(),
pl.col('FLARING').sum(),
pl.col('PER_CAP').sum(),
)
.with_columns(YEAR = pl.lit('NA'))
.sort('DECADE')
.collect() # dataframe
)
df_decade_diff = (
df_decade
.lazy() # lazyframe
.with_columns(
pl.col(
'FOSSIL', 'SOLID', 'LIQUID', 'GAS',
'CEMENT', 'FLARING', 'PER_CAP'
).diff()
)
.collect() # dataframe
)
#----- CALLBACK FUNCTIONS ------------------------------------------------------
def get_corr_stat(stat, corr_x, corr_y, group_by):
df_plot = df_year.drop_nulls([corr_x, corr_y])
if group_by == 'DECADE':
df_plot = df_decade.drop_nulls([corr_x, corr_y])
res = stats.linregress(df_plot[corr_x], df_plot[corr_y])
if stat == 'SLOPE':
val = res.slope
elif stat == 'INTERCEPT':
val = res.intercept
elif stat == 'CORR':
val = res.rvalue**2
elif stat == 'STDERR':
val = res.stderr
elif stat == 'I_STDERR':
val = res.intercept_stderr
else:
print('illegal value, unrecognized stat')
val = -999999
return val
def get_data_plot(data_type, group_by, graph_type):
if (data_type, group_by) == ('DATA', 'YEAR'):
df_plot = df_year
graph_title = f'<b>{graph_type} PLOT BY {group_by}</b>'
y_axis_label = 'TOTAL BY YEAR'
if (data_type, group_by) == ('DIFF', 'YEAR'):
df_plot = df_year_diff
graph_title = f'<b>{graph_type} PLOT INCREMENTAL, {group_by} / {group_by}</b>'
y_axis_label = 'YEAR/YEAR'
if (data_type, group_by) == ('DATA', 'DECADE'):
df_plot = df_decade
graph_title = f'<b>{graph_type} PLOT BY {group_by}</b>'
y_axis_label = 'TOTAL BY DECADE'
if (data_type, group_by) == ('DIFF', 'DECADE'):
df_plot = df_decade_diff
graph_title = f'<b>{graph_type} PLOT INCREMENTAL, {group_by} / {group_by}</b>'
y_axis_label = 'DECACE/DECADE'
if graph_type == 'LINE':
fig=px.line(
df_plot,
group_by,
short_col_names[1:-1],
)
if graph_type == 'AREA':
fig=px.area(
df_plot,
group_by,
short_col_names[1:-1],
)
fig.update_layout(
template='simple_white',
title_text=graph_title,
yaxis=dict(title=dict(text=y_axis_label))
)
if group_by == 'YEAR':
int_years = sorted(
[int(x) for x in df_plot['YEAR'].unique() if int(x)%10 ==0]
)
fig.update_xaxes(
tickangle=90,
tickmode = 'array',
tickvals = [x for x in int_years if x%10 ==0],
ticktext= [str(x) for x in int_years if x%10 ==0]
)
return fig
def get_corr_plot(corr_x, corr_y, group_by):
if group_by == 'YEAR':
df_plot = df_year.drop_nulls([corr_x, corr_y])
if group_by == 'DECADE':
df_plot = df_decade.drop_nulls([corr_x, corr_y])
regression_params = stats.linregress(df_plot[corr_x], df_plot[corr_y])
x_min = df_plot[corr_x].min()
x_max = df_plot[corr_x].max()
# find values for y at x_min and x_max using y = mx + b
y_at_x_min = (regression_params.slope * x_min) + regression_params.intercept
y_at_x_max = (regression_params.slope * x_max) + regression_params.intercept
fig=px.scatter(
df_plot,
x=corr_x,
y=corr_y,
color='DECADE',
)
fig.add_trace(
go.Scatter(
x=[x_min, x_max],
y=[y_at_x_min, y_at_x_max],
mode='lines',
line=dict(dash='longdashdot',width=3, color='lightgray'),
)
)
fig.update_layout(
template='simple_white',
title_text=f'<b>CORRELATION PLOT BY {group_by}</b>',
xaxis=dict(title=dict(text=f'{corr_x}')),
yaxis=dict(title=dict(text=f'{corr_y}')),
showlegend=False,
)
return fig
def get_table(group_by):
if group_by == 'YEAR':
df = df_year.select(dag_columns)
if group_by == 'DECADE':
df = (
df_decade
.select(dag_columns)
)
return df.to_dicts()
#----- DASH APPLICATION STRUCTURE-----------------------------------------------
app = Dash(external_stylesheets=[dbc.themes.LITERA])
app.layout = dmc.MantineProvider(
[
html.Hr(style=style_horiz_line),
html.H2('CO2 EMISSIONS DATA', style=style_h2),
html.H3(data_src, style=style_h3),
html.Hr(style=style_horiz_line),
dbc.Row([ # cols 2 & 3 for Group by, 5 & 6 for Plot type
dbc.Col(html.Div('Group by:'), width={'size': 2, 'offset': 1}),
dbc.Col(html.Div('Plot type:'), width={'size': 2, 'offset': 1}),
]),
dbc.Row([
dbc.Col([
dcc.RadioItems(
['DECADE', 'YEAR'], 'YEAR', inline=False,
labelStyle={'margin-right': '30px',},
id='group_by_radio',
),],
width={'size': 2, 'offset': 1} # cols 2 & 3
),
dbc.Col([dcc.RadioItems(
['AREA', 'LINE'], 'AREA', inline=False,
labelStyle={'margin-right': '30px',},
id='graph_type_radio',
),],
width={'size': 2, 'offset': 1}), # column 5 to 6
]),
html.Div(),
dbc.Row(
[
dbc.Col(dcc.Graph(id='graph_plot'), width=6),
dbc.Col(dcc.Graph(id='graph_diff'), width=6),
]
),
html.Div(),
html.Hr(style=style_horiz_line),
html.H2('Correlations', style=style_h2),
html.H3('Pearson values from scipy.stats', style=style_h3),
html.Hr(style=style_horiz_line),
dbc.Row([
dbc.Col(html.Div('X-Axis:'), width={'size': 1, 'offset': 1}),
dbc.Col([
dcc.RadioItems(
sorted(short_col_names[1:-1]),
sorted(short_col_names[1:-1])[0],
inline=True,
labelStyle={'margin-left': '30px','margin-right': '30px'},
id='corr_x_radio',
),
],
width={'size': 10, 'offset': 0}),
]),
html.Div(),
dbc.Row([
dbc.Col(html.Div('Y-Axis:'), width={'size': 1, 'offset': 1}),
dbc.Col([
dcc.RadioItems(
sorted(short_col_names[1:-1]),
sorted(short_col_names[1:-1])[2],
inline=True,
labelStyle={'margin-left': '30px','margin-right': '30px'},
id='corr_y_radio',
),
],
width={'size': 10, 'offset': 0}
),
]),
html.Div(),
html.Div("", className="w-25 p-3 bg-transparent border-0"),
dbc.Row([
dbc.Col(dcc.Graph(id='graph_corr')),
dbc.Col(regression_stats_card)
]),
html.Div("", className="w-25 p-3 bg-transparent border-0"),
html.Div(),
html.Hr(style=style_horiz_line),
html.H2('Data and Definitions',id='data_and_defs',style=style_h2),
html.Hr(style=style_horiz_line),
dbc.Row([
dbc.Col([grid], width=8),
dbc.Col(definition_card, width=4),
])
]
)
@app.callback(
Output('graph_plot', 'figure'),
Output('graph_diff', 'figure'),
Output('graph_corr','figure'),
Output('dash_ag_table', 'rowData'),
Output('lg_slope_val','children'),
Output('lg_intcpt_val','children'),
Output('lg_corr_val','children'),
Output('lg_stderr','children'),
Output('lg_i_stderr','children'),
Output('data_and_defs','children'),
Input('group_by_radio', 'value'),
Input('graph_type_radio', 'value'),
Input('corr_x_radio', 'value'),
Input('corr_y_radio', 'value'),
)
def update_dashboard(group_by, graph_type, corr_x, corr_y):
data_defs_title = 'Data and Definitions'
if group_by == 'DECADE':
data_defs_title = 'Data (grouped by decade) and Definitions'
return (
get_data_plot('DATA', group_by, graph_type),
get_data_plot('DIFF', group_by, graph_type),
get_corr_plot(corr_x, corr_y, group_by),
get_table(group_by),
f'{get_corr_stat('SLOPE', corr_x, corr_y, group_by):.3f}',
f'{get_corr_stat('INTERCEPT', corr_x, corr_y, group_by):.3f}',
f'{get_corr_stat('CORR',corr_x, corr_y, group_by):.3f}',
f'{get_corr_stat('STDERR', corr_x, corr_y, group_by):.3f}',
f'{get_corr_stat('I_STDERR', corr_x, corr_y, group_by):.3f}',
data_defs_title
)
if __name__ == '__main__':
app.run_server(debug=True)
